The Vaisala DMT345 and DMT346 provided direct dew-point measurement in hot industrial drying processes. Both models are discontinued and replaced by Vaisala DMP5 or DMP6 smart probes with an Indigo transmitter.
DMT345: former solution for processes up to +180 °C
DMT346: former solution for very hot processes up to +350 °C
DMT345 replacement: DMP5 with a suitable Indigo transmitter
DMT346 replacement: DMP6 with a suitable Indigo transmitter
Direct in-process measurement without a conventional sampling system
Contact Seacom for mechanical and electrical migration review
The Vaisala DMT132 is a compact and economical dew-point transmitter designed to verify refrigerant-dryer performance by measuring the actual outlet-air dew point.
Dew-point measurement range from −30 to +50 °C Td/f
Accuracy up to ±1 °C in the typical refrigerant-dryer range
The Vaisala DMT152 provides accurate dew-point measurement down to −80 °C Td/f for ultra-dry industrial and OEM applications. This model is discontinued and has been replaced by the Vaisala DMT153.
Calibrated dew-point range from −80 to −20 °C Td/f
Accuracy up to ±2 °C Td/f
Operating pressure up to 50 bar
Analog outputs and RS-485 communication
DRYCAP® sensor resistant to condensation and contamination
The Vaisala DMT143 and DMT143L provide compact, dependable dew-point measurement for small industrial dryers, compressed-air systems, glove boxes and OEM equipment.
Dew-point measurement range across the family from −70 to +60 °C Td/f
Accuracy up to ±2 °C Td/f
Vaisala DRYCAP® technology with automatic calibration
Resistant to condensation, compressor oil and particulate contamination
Analog output and RS-485 with Modbus RTU options
Compatible with the Vaisala Indigo80 handheld indicator
The compact Vaisala HM40 Series provides reliable humidity and temperature spot checks for HVAC, construction, warehouses, laboratories, museums and industrial applications.
The Vaisala PTU300 combined barometric pressure, relative humidity and temperature in one transmitter. The series is discontinued and has been replaced by a suitable Indigo520 barometric-pressure configuration with an application-specific HMP probe.
Legacy three-in-one pressure, humidity and temperature transmitter
PTU301, PTU303, PTU304, PTU305, PTU307 and PTU308 variants
Former applications include laboratories, meteorology and semiconductor measurement
Current replacement platform: Indigo520 with barometric-pressure measurement
Humidity probe selected according to mounting and process conditions
Existing wiring, outputs and process connections require migration review
The Vaisala HMT120 and HMT130 provide accurate, stable humidity and temperature measurement for cleanrooms, laboratories, data centres and demanding HVAC applications.
Product transition: HMT120/HMT130 are expected to be phased out. For new projects, the Vaisala Origo10 is the recommended replacement platform.
The Vaisala DPT146 combines dew-point and process-pressure measurement in one compact transmitter for compressed-air systems. This model is discontinued and should not be selected for new projects.
Dew-point measurement from −70 to +30 °C Td
Absolute-pressure measurement from 1 to 12 bar
Pressure-compensated dew point and ppm calculation
Analog outputs and RS-485 with Modbus RTU
Contact Seacom for existing-unit support and replacement assessment
The Vaisala HM70 was a handheld meter for humidity and temperature spot checks, field measurements, data logging and verification of installed Vaisala instruments. It is discontinued and replaced by the Vaisala Indigo80 handheld indicator with an HMP80 probe.
Legacy MI70 handheld indicator with HMP75, HMP76 or HMP77 probe
Relative-humidity measurement from 0 to 100 %RH
Probe-dependent temperature measurement from −70 to +180 °C
Numerical and graphical display with portable data recording
Current replacement: Indigo80 with HMP80N or HMP80L
HMP80N for general measurements; HMP80L for extended temperature reach
The Vaisala DM70 was a portable meter for dew-point spot checks, process measurements and data logging. It is discontinued and replaced for general dew-point work by the Vaisala Indigo80 handheld indicator with a DMP80A or DMP80B probe.
Legacy DMP74A, DMP74B and SF₆-specific DMP74C probe options
Direct or sampled measurement in pressurised processes
Portable numerical and graphical display with data logging
Current replacement: Indigo80 with DMP80A or DMP80B
DMP80A for moderate dew points down to −40 °C Td/f
The Vaisala HMW90 Series provides high-accuracy humidity and temperature measurement for demanding indoor HVAC and controlled-environment applications.
Humidity accuracy up to ±1.7% RH
Analog or Modbus RTU output models
Optional display and configurable relay
Replaceable measurement module with calibration certificate
