    Hyoda KME-2 & KME-4 Temperature Controllers | Seacom

Hyoda KME-2 & KME-4 Temperature Controllers with Microswitch

The Hyoda KME-2 and KME-4 provide temperature switching through a remote sensing bulb and one microswitch contact.

  • KME-2 includes a temperature indicator.
  • KME-4 operates without a temperature indicator.
  • Liquid-filled and gas-filled configurations.
  • Wall-mounted enclosure with IP43 drip-proof protection.
  • Published contact rating: AC 125 V or 250 V / 5 A.

Need advice or a quotation?

Ask Seacom about specifications, availability and the right instrument for your application.

Hyoda KME-2 and KME-4 Temperature Controllers with Microswitch

The Hyoda KME-2 and KME-4 are fluid-filled temperature controllers with a remote sensing bulb and one microswitch contact. Their wall-mounted arrangement allows the switching instrument to be installed separately from the measurement point.

Choose KME-2 when local temperature indication is needed, or KME-4 when switching is required without a local indicator. Specify the temperature scale, sensing bulb, connection and capillary arrangement for the installation.

Compare KME Models

FeatureKME-2KME-4
Temperature indicator Included Not included
Microswitch One contact One contact
Mounting Wall-mounted Wall-mounted
Enclosure protection IP43, drip-proof IP43, drip-proof
Selection focus Switching with local temperature reading Switching without a local temperature display

Specifications and Options

SpecificationDetails
Measuring system Liquid-filled or gas-filled, depending on configuration
Liquid-filled range coverage −70 to 400°C
Gas-filled range coverage −200 to 600°C
Published capillary lengths Liquid-filled, single capillary: 10 m; gas-filled: 50 m
Published contact rating AC 125 V or 250 V / 5 A
Contact terminals At the lower part of the instrument enclosure

Range coverage describes available configurations, not the scale of every instrument. Confirm the selected standard scale, switching point, bulb dimensions, connection and permissible capillary length before ordering.

KME-2: With Temperature Indicator

A practical choice when an operator needs to read the temperature at the controller as well as use its switching contact.

Hyoda KME-2 temperature controller with indicator and dimensional information

KME-4: Without Temperature Indicator

Suitable when the application needs the switching function and a local temperature display is not required.

Hyoda KME-4 temperature controller without indicator and dimensional information

Choosing the Right Configuration

  • Temperature: provide the operating range, expected extremes and required switching point.
  • Local reading: decide whether the operator needs an indicator at the controller.
  • Electrical circuit: specify voltage, current and load type so contact suitability can be checked.
  • Sensing bulb: confirm insertion length, diameter, process connection and any thermowell dimensions.
  • Capillary route: measure the route from the sensing point to the controller, allowing for installation access and protection from damage.
  • Environment: check that IP43 protection suits the mounting location and exposure.

Compare All Six Hyoda Thermometer Listings

Product / rangeInstrument typeDisplay / arrangementIndication / switchingProtectionSelection focus
M Series Fluid-filled; M3/M4/M6 and WP versions 75 / 100 / 150 mm; remote bulb Optional pointer contacts; M3: one, M4/M6: one or two IP43; WP: IP65 Remote reading with a choice of dial sizes
S6 / S6-WP Fluid-filled 150 mm; remote bulb Indication only or one/two pointer contacts IP43; WP: IP65 Large dial for remote temperature indication
AY Series Bimetal; AY4/AY5 and QS versions 100 / 125 mm; stem-mounted; QS adjustable head Temperature indication IP65 Local reading at the sensing stem
KME-2 / KME-4 Fluid-filled; wall-mounted KME-2: with indicator; KME-4: without indicator One microswitch contact IP43 Temperature switching with or without local indication
ES-UT Liquid-filled; wall-mounted Remote sensing bulb One or two microswitch contacts IP65; published explosion-proof designation d2G4 Applications requiring a suitable explosion-protected controller; confirm approval suitability
Fluid-Filled Thermometer Range General range listing; multiple configurations Depends on selected model Depends on selected model Depends on selected model Explore other Hyoda temperature indication and control options

The Fluid-Filled Thermometer Range is an overview listing, not a single model with one specification. Compare the exact model, temperature scale, sensing bulb, connection and mounting before ordering. S6 and M6 both have 150 mm dials, but this does not establish interchangeability.

Related Hyoda Thermometers

  • S6 / S6-WP — Fluid-filled thermometer with a 150 mm dial, remote sensing bulb and a choice of IP43 or IP65 enclosure.
  • M Series — Fluid-filled thermometers with 75, 100 or 150 mm dials, remote sensing bulbs and optional pointer contacts.
  • ES-UT — Liquid-filled controller with one or two microswitch contacts and an explosion-proof enclosure; confirm approval suitability for the installation.
  • AY Series — Bimetal thermometers for local indication, with 100 or 125 mm dials and adjustable-head QS versions.
  • Fluid-Filled Thermometer Range — Explore other Hyoda configurations for temperature indication and control, selected according to the measurement and installation requirements.

Need Help Selecting a KME Temperature Controller?

Contact Seacom with your temperature range, switching point, electrical load, connection and capillary length requirements. For a replacement, include photographs of the existing nameplate and installation so we can help check the appropriate model and configuration.
