Anritsu MG Series Magnetic Surface Temperature Probes

The Anritsu MG Series magnetic temperature probes attach to suitable stationary surfaces for surface temperature measurement.

  • Built-in magnets for secure attachment to magnetically receptive surfaces.
  • Type K and Type E thermocouple configurations.
  • Temperature ranges from −50°C to 250°C or 400°C, depending on the model.
  • Different sensing heads and cable options to suit the installation.

Anritsu MG Series Magnetic Surface Temperature Probes

The Anritsu MG Series uses built-in magnets to hold the sensing head against a stationary measurement surface. These probes provide a practical way to take surface temperature readings where the target material allows secure magnetic attachment.

Key Features

  • Magnetic attachment for stationary surface measurements.
  • Type K and Type E thermocouple configurations.
  • Selected models rated from −50°C to 250°C or −50°C to 400°C.
  • Different head designs and cable configurations to suit the installation.

Anritsu MG Series magnetic surface temperature probes

Compare MG Probe Models

The following are complete example configurations. Confirm the full order code, thermocouple type and connection before ordering.

ProbeType K exampleType E exampleTemperature range
MG-11 MG-11K-TS1-ANP MG-11E-TS1-ANP −50 to 250°C
MG-64 MG-64K-GW1-ANP MG-64E-GW1-ANP −50 to 400°C
MG-21 MG-21K-TS1-ANP MG-21E-TS1-ANP −50 to 250°C
MG-24 MG-24K-GW1-ANP MG-24E-GW1-ANP −50 to 400°C
MG-33 MG-33K-TA1-ANP MG-33E-TA1-ANP −50 to 250°C
MG-34 MG-34K-GX1-ANP MG-34E-GX1-ANP −50 to 400°C

Probe Selection and Dimensions

Anritsu MG Series model selection and probe dimensions

Model Pictures and Order Codes

Each model below groups its original drawing with the complete Type K and Type E example codes and temperature range.

MG-11 Magnetic Probe

SpecificationMG-11

Anritsu MG-11 magnetic surface temperature probe
Type K order code MG-11K-TS1-ANP
Type E order code MG-11E-TS1-ANP
Temperature range −50 to 250°C

MG-64 Magnetic Probe

SpecificationMG-64

Anritsu MG-64 magnetic surface temperature probe
Type K order code MG-64K-GW1-ANP
Type E order code MG-64E-GW1-ANP
Temperature range −50 to 400°C

MG-21 Magnetic Probe

SpecificationMG-21

Anritsu MG-21 magnetic surface temperature probe
Type K order code MG-21K-TS1-ANP
Type E order code MG-21E-TS1-ANP
Temperature range −50 to 250°C

MG-24 Magnetic Probe

SpecificationMG-24

Anritsu MG-24 magnetic surface temperature probe
Type K order code MG-24K-GW1-ANP
Type E order code MG-24E-GW1-ANP
Temperature range −50 to 400°C

MG-33 Magnetic Probe

SpecificationMG-33

Anritsu MG-33 magnetic surface temperature probe
Type K order code MG-33K-TA1-ANP
Type E order code MG-33E-TA1-ANP
Temperature range −50 to 250°C

MG-34 Magnetic Probe

SpecificationMG-34

Anritsu MG-34 magnetic surface temperature probe
Type K order code MG-34K-GX1-ANP
Type E order code MG-34E-GX1-ANP
Temperature range −50 to 400°C

Measurement Notes

For these examples, Anritsu specifies a tolerance of ±2.5°C at a surface temperature of 100°C and a response time of 2 seconds under its test conditions. These figures are not a guarantee of the same performance on every surface.

The sensing head rating does not establish the permitted temperature of the cable or connector. Keep those components within their respective limits.

Choosing the Right Magnetic Probe

  • Target surface: confirm that the material accepts a magnet and that the head can sit securely. Not every metal is suitable for magnetic attachment.
  • Contact conditions: check surface shape, coatings, cleanliness and access. Poor contact can affect the reading.
  • Temperature: select a head and cable combination suitable for the complete operating conditions.
  • Instrument connection: match the thermocouple type and connector to the thermometer or data logger.
  • Measurement task: these probes measure the contacted surface; do not assume that reading equals an internal fluid or process temperature.

Additional and Earlier Model References

The existing Seacom page also lists the references below. Some are abbreviated or earlier references. Send the complete label or order code so we can check the appropriate specification and supply options; do not assume an automatic replacement.

Model / referenceModel / reference
MG-11K MG-12K
MG-21K MG-22K
MG-13 MG-23
MG-22 MG-62

Related Anritsu Temperature Instruments

Instrument links are provided for comparison. Confirm the input type, connector and required measuring range before pairing a probe with an instrument.

Need Help Selecting an MG Probe?

Contact Seacom Process Instruments Sdn Bhd with the target material, surface shape, operating temperature, cable length and thermometer model. For a replacement, include a photograph of the existing probe and its complete model number.

Email Seacom or contact us on WhatsApp.

Download

  MG Series Catalogue   (1.46M)
