Surface Temperature Calibrator ACS Series

Anritsu ACSⅡ series products are temperature calibration systems for surface temperature and internal temperature measuring devices.

Temperatures can be set across a wide range, from room temperature to 500°C. These calibration systems are designed for calibration or to check temperature measuring probes.

ACSⅡ-1000

ACSII-1000

For Surface Temperature Max. 300°C

Surface Range: Rt to 300°C
Dimensions , Weight:
Control Unit 320*177*350(mm) , 4.5(kg)
Calibration Unit 260*130*260(mm) , 7(kg)

ACSⅡ-2000

ACSII-2000

For Surface Temperature Max. 500°C

Surface Range: Rt to 500°C
Dimensions , Weight:
Control Unit 320*177*350(mm) , 4.5(kg)
Calibration Unit 390*230*360(mm) , 20(kg)

ACSⅡ-3000

ACSII-3000

For Internal Temperature Max. 500°C

Internal Range: Rt to 500°C
Dimensions , Weight:
Control Unit 420*177*350(mm) , 5(kg)
Calibration Unit 450*405*400(mm) , 70(kg)

ACSII-4000

ACSII-4000

For Suface and Internal Temperature Max. 500°C

Surface Range: Rt to 500°C
Internal Range: Rt to 500°C
Dimensions , Weight:
Control Unit 420*177*350(mm) , 5(kg)
Calibration Unit 450*405*400(mm) , 70(kg)



Overall Accuracy

Model ACSII-1000 ACSII-2000 ACSII-3000 ACSII-4000
Calibration Object Surface Surface Internal Surface  Internal
Range Rt to 100°C +0.5°C
-0.7°C
+0.5°C
-0.7°C
±0.26°C +0.4°C
-0.6°C
±0.26°C
100.1 to 200.0°C +0.5°C
-1.1°C
+0.5°C
-1.1°C
±0.32°C +0.3°C
-0.9°C
±0.32°C
200.1 to 300.0°C +0.5°C
-1.5°C
+0.5°C
-1.5°C
±0.37°C +0.1°C
-1.1°C
±0.37°C
300.1 to 400.0°C +0.4°C
-2.0°C
±0.43°C -0.2°C
-1.5°C
±0.43°C
400.1 to 500.0°C -0.1°C
-2.9°C
±0.48°C -0.9°C
-2.2°C
±0.48°C



Control Unit

Model ASCII-1000 ACSII-2000 ACSII-3000 ACSII-4000
Range  Rt to 300°C Rt to 500°C Rt to 500°C
Control Principle PID auto-Tuning Control
Control Input Pt100Ω φ3.2
Accuracy ±(0.2% of reading)℃
Display 8mm high LED display
Reference
Sensor
Input - Pt100Ω Φ4.8mm JIS C 1604
Accuracy - ±(0.05% of reading+0.05)℃
Display - 12.5mm high LED display
Power supply AC100V~240V * Please select
Power Consumption app.160W app.700W app.1600W



Calibration Unit

model ACSII-1000 ACSII-2000 ACSII-3000 ACSII-4000
Testing Surface (mm) φ78mm φ100mm - □150mm
Test Point - 8 holes based on specified dimension
Temp. Distribution Surface ±0.1°C - ±0.1°C
Temp. Distribution Internal - ±0.1°C
Heater 150W 600W 1500W
Overheating prevention mechanism Bimetal breaker
Heating time Rt → 150°C 25min Rt → 300°C 50min Rt → 250°C 30min Rt → 500°C 60min Rt → 250°C 60min Rt → 500°C 150min
Cooling time 300 → 150°C 80min 150 → 50°C 120min 500→250°C 40min
250→50°C 90min
500→250°C 220min
250→100°C 450min



Supplied accessories

Model ACSⅡ-1000 ACSⅡ-2000 ACSⅡ-3000 ACSⅡ-4000
Supplied accessories Power cable,Heater cable, Sensor cable, Manual,Test report
Protective cover for calibration block Standard sensor for calibration
(Pt 100Ω platinum resistor)

Specific References

Download

ACS Series Catalogue

Surface Temperature Calibrator ACS Series

Download (753.59k)
