Technical Data

Relative Humidity Measurement Performance

Humidity Sensor Options:
HUMICAP R2 / Latest generation industrial sensor with improved corrosion resistance
HUMICAP 180V / Humidity sensor with a catalytic surface for processes with H₂O₂

Measurement range / 0 ... 100 %RH
Stability / ±0.5 %RH/year in typical HVAC applications

Accuracy at 0 ... +40 °C (+32 ... +104 °F) 1)
0 ... 90 %RH / ±1.5 %RH
90 ... 100 %RH / ±2.5 %RH

Accuracy at +40 ... +80 °C (+104 ... +176 °F) and -40 ... 0 °C (-40 ... +32 °F) 1) 2)
0 ... 90 %RH / ±2.5 %RH
90 ... 100 %RH / ±3.5 %RH

Factory calibration uncertainty / ±1.0 %RH

Start-up and Response Time
Start-up time at +20 °C (+68 °F) / 8 s
Response time (T63) at +20 °C (+68 °F) / 15 s

Calculated Humidity Parameters (Default Analog Output Scale)
Dew point / -40 ... +80 °C (-40 ... +176 °F)
Dew point / frost point / -40 ... +80 °C (-40 ... +176 °F)
Absolute humidity / 0 ... 300 g/m³ (0 ... 131.1 gr/ft³)
Wet bulb temperature / -40 ... +80 °C (-40 ... +176 °F)
Enthalpy / -40 ... 1600 kJ/kg (-9.5 ... 695.6 Btu/lb)
Mixing ratio / 0 ... 600 g/kg (0 ... 4200 gr/lb)

*Including non-linearity, hysteresis, and repeatability

*With HUMICAP 180V sensor, accuracy is not specified below -20 °C (-4 °F) operating temperature

Temperature Measurement Performance

Temperature sensor / Pt1000 RTD Class F 0.1 IEC 60751
Measurement range / -40 ... +80 °C (-40 ... +176 °F)
Default analog output scale / -20 ... +80 °C (-4 ... +176 °F)
Accuracy at +20 °C (+68 °F) / ±0.1 °C (0.18 °F)
Temperature dependence / ±0.005 °C/°C
Factory calibration uncertainty / ±0.1 °C (0.18 °F)
Response time (T63) with free convection / 8 min

Analog Output Performance

Accuracy at +20 °C (+68 °F):
±0.01 mA (HMD62 and TMD62)
±5 mV (HMD65)

Temperature dependence:
±0.0008 mA/°C (HMD62 and TMD62)
±0.2 mV/°C (HMD65)

Operating Environment

Operating temperature, electronics / -40 ... +60 °C (-40 ... +140 °F)
Operating temperature, probe / -40 ... +80 °C (-40 ... +176 °F)
Storage temperature range / -40 ... +80 °C (-40 ... +176 °F)
Maximum flow speed / 50 m/s with sintered filter
Electromagnetic compatibility / EN61326-1, Industrial Environment

Inputs and Outputs

Power supply input:
HMD62 and TMD62: 10 ... 35 VDC (RL = 0 Ω), 20 ... 35 VDC (RL = 600 Ω)
HMD65: 15 ... 35 VDC, 16 ... 24 VAC

Power consumption (HMD65) / 1.0 W (typical, for both AC and DC)

Analog outputs:
TMD62: 1 × T output 4 ... 20 mA
HMD62: 1 × RH output 4 ... 20 mA, 1 × T output 4 ... 20 mA 1)
HMD65: 1 × RH output 0 ... 10 V, 1 × T output 0 ... 10 V 1) (load resistance: 10 kΩ min.)

Digital output (RS-485) / HMD65: Isolated, supports Modbus RTU and BACnet MS/TP protocols
BACnet MS/TP / Address range: 0 ... 127 (master mode only)
Modbus RTU / Address range: 1 ... 247

Service port / M8 4-pin male connector:

*HM70 handheld indicator (requires cable 219980SP)

*Vaisala Insight PC software 2) (requires USB cable 219690)

*Screw terminal wire size / 0.5 ... 2.5 mm²Calculated output parameters for HMD62 and HMD65 include Td, Tf, a, Tw, h, and x.

*Vaisala Insight software for Windows available at vaisala.com.

Spare Parts and Accessories

USB cable for PC operation (Vaisala Insight software) / 219690
Connection cable for HM70 (MI70) handheld meter / 219980SP
Membrane filter / ASM212652SP
Sintered filter / HM46670SP
Sintered teflon filter / DRW244938SP
Conduit fitting and O-ring (M16×1.5 / NPT1/2") / 210675SP

Mechanical Specification

Housing material / Cast aluminum
Probe material / Stainless steel
IP rating / IP66 (NEMA 4X)
Weight / 511 g (18 oz)
