Universal Input Data Recorder (FDA Approved)

The Vaisala 4000 Series of data recorders are designed to interface with a wide range of transducers, transmitters, and sensors with a DC voltage or 0 - 20 mA current loop output.

The Vaisala 4000 is a simple solution for recording and monitoring pressure, flow, fluid level, PH, electrical properties, moisture and gas concentrations. Ideal for use in standalone or networked applications, the 4000 Universal Input recorder connects directly to a PC with USB or installs to an existing network via Ethernet, Power over Ethernet or WiFi. Each recorder contains a 10-year battery and onboard memory for recording a wide range of variables at the point of measurement. With autonomous power and recording capacity, data is immune to network and power interruptions.

The Vaisala 4000 data recorders can be used with Vaisala software to download, display, and analyze environmental data as well as provide tamper-proof electronic records that meet 21 CFR Part 11 requirements.

The optional browser-based viewLincTM system provides 24/7 multi-stage alarm notification, remote, real-time monitoring and gap-free data. Reports are customizable and can be exported to excel and PDF.

Model Vaisala 4000
Fixed / Portable Fixed
Measurement Range -40 °C to +85 °C
Accuracy ±0.15 % F.S. at +25 °C
Remarks ▪ Long-life 10-year battery and large onboard memory

▪ Single and multi-channel models with up to four input channels

▪ Easily set scaling and measurement units for recording

▪ Time-based digital recording in a range of sample intervals

▪ Multiple connectivity options - USB, Ethernet, WiFi

▪ Optional vNet cradle for Ethernet or Power over Ethernet connectivity

▪ NIST-traceable calibration

▪ Two year limited warranty
